STATUS DISPLAY

The four ring-shaped LED lights allow precise and shadowless work. Status information is displayed by the LED indicator on the back of the hot glue gun. A red light stands for heating up, a green light for ready to use and a red flashing light symbolizes that you need to refill a new glue stick.

red light: heating up

blue light: ready for use

flashing light: refill glue stick

Contents

› 1 cordless hot glue gun (with permanently installed rechargeable Li-ion battery)

› 1 USB charging cord (USB type-C)

› 7 glue sticks ø 7 mm (each: transparent, yellow, orange, purple, blue, green, pink)

› 2 spring holders

› 1 instruction manual (this manual)

Technical data

Item No. DHT0003

Model No. D890401

Weight w/o packaging Approx. 300 g

Rated voltage 3.6 V DC

Heating-up time Approx. 15 seconds

Automated switch-off After 2 minutes of non-use Temperature 160 °C

Glue stick diameter 7 mm

Glue stick length 150 mm

Battery type Li-ion battery Battery capacity 4Ah

Number of batteries 1

Recommended charger 5V/2A

Warranty

The warranty period is 2 years and starts on the date of sale to the customer. We will remedy all kind of defects caused by material damage and/or manufacturing faults. The warranty will be met by repair or replacement of defective parts at our own discretion. Claims under warranty will only be accepted if the tool is sent fully assembled and well packaged complete with cash voucher or invoice to the appropriate dealer within the first six months. Improper use voids the warranty.
